MSI

MSI B650 Gaming Plus WIFI Motherboard - Socket AM5

Sold out
£143.95
⭐Earn 1001 TCG Points with this item⭐
🚚 Delivery & Shipping

Delivery options are shown at checkout based on your basket, location and item size.

Most UK orders are sent with Royal Mail, DPD, Parcelforce or UPS. In-stock items are usually dispatched quickly on working days, but dispatch may take longer for pre-orders, back-orders, large items, mixed baskets, busy periods or orders requiring security checks.

Typical UK delivery aims:

  • Economy Delivery: 4–7 working days
  • Standard Delivery: 3–5 working days
  • Express Delivery: 1–3 working days
  • Large / heavy items: shown at checkout

Tracking details will be emailed once your order has been dispatched. Courier tracking may take a short time to update.

For urgent orders or release-day delivery questions, please contact us before ordering.

contact@thechelseagamer.email / 020 3141 3400

Description

B650 GAMING PLUS WIFI
Defeat the Competition
The B650 GAMING PLUS WIFI is designed with tons of connectivity, flexible tools, a convenient Wi-Fi solution and DDR5 memory support for gamers who want it all.

  • Supports AMD Ryzen 7000 Processors (Zen 4, AM5)
  • 12 Duet Rail Power System
  • 4 x DDR5 DIMMs with Memory Boost: Dual Channel (128GB Max. / 6000MHz OC)
  • 2 x PCI-e 4.0 x16 slots
  • Lightning Gen4 M.2 & M.2 Shield Frozr
  • 7.1 HD Audio with Audio Boost
  • USB 3.2 Gen 2x2 Type-C (20Gbps)
  • Realtek 2.5G LAN, AMD Wi-Fi 6E & Bluetooth 5.3
Features

Supports AMD Ryzen 7000 Processors
The B650 GAMING PLUS WIFI motherboard supports AMD Ryzen 7000 processors.
Form Factor: ATX
Socket Type: AM5
Chipset: AMD B650

12+2 Duet Rail Power System VRM Design
With its dual 8 pin power connectors and exclusive Core Boost technology, the B650 GAMING PLUS WIFI is able to sustain heavy CPU power loads to support system-demanding game settings:
1. Digital PWM IC
2. 12-Phase Duet-Rail CPU Power
3. 2-Phase SOC Power
4. 1-Phase MISC Power

Integrated Cooling Features
VRM Cooling: Features an extended heatsink, 7W/mK thermal pads and additional choke thermal pads for improved thermal dissipation.

PCB Cooling: Premium 6-layer printed circuit design with 2 oz. thickened copper improves heat dissipation & reliability.

SSD Cooling: M.2 Shield Frozr prevents thermal throttling.

System Cooling: Connect and synchronize cooling with strategically placed pin-headers - including a dedicated pump-fan header.

4 x DDR5 Dual Channel (6000+ MHz OC)*
Memory Boost: A fully-isolated DDR circuit delivers pure data signals for optimal gaming and overclocking performance.

Memory OC profiles in MSI BIOS are MSI OC LAB optimized and can be easily enabled with auto power settings for optimized memory speed and stability.

*1DPC 1R Max. overclocking frequency 6000 MHz, supports AMD EXPO.

2 x Fortified PCI-e 4.0 x16 Slots
MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points to support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor also shields the point of contact from electromagnetic interference.

2 x PCI-e 4.0/3.0 x16 slots* (primary with Steel Armor)
*Supports x16/x4

Gen4 M.2 Connectors
The B650 GAMING PLUS WIFI motherboard features MSI's Gen4 M.2 slots:
2 x Gen4 x4 64Gbps slots*
*1 with M.2 Shield Frozr

M.2 Shield Frozr
Even the world’s fastest SSDs will automatically slow if thermal throttling firmware detects excessively high temperatures.

M.2 Shield Frozr is MSI's most advanced thermal solution, offering the best possible protection to ensure maximum SSD transfer speed performance.

Wi-Fi 6E & Bluetooth 5.3
2.5G LAN: A Realtek 2.5Gbps LAN controller delivers a premium network gaming experience.

USB 3.2 Gen 2x2 Type-C: Connect to devices and transfer files at high bandwidth rates: 20Gbps.

Wi-Fi 6E: Features the latest AMD Wi-Fi 6E module (ultra-low latency, high-bandwidth) & Bluetooth 5.3 technology.

HD Audio: 7.1-Channel High Definition Audio with Audio Boost.

Data Sheet

B650 GAMING PLUS WIFI - Data Sheet
